E-2 MTR3000 Third Party Controllers: Community Repeater Panel
Figure E-1 CPS settings to configure MTR3000 Base Station/Repeater for analog mode
E.2 Community Repeater Panel
E.2.1 Description
The MTR3000 Base Station/Repeater is capable of Multi Coded Squelch through the Zetron Model
38 Repeater Panel. The Model 38 Repeater Panel interconnects to the MTR3000 Base Station/
Repeater and provides 38 PL tones and 22 DPL tones standard.
Refer to Zetron Model 38 Repeater Panel Instruction Manual (supplied with the panel) for panel
specifications, operation, installation, alignment, programming, and repair information.
Figure E-2 Model Zetron 38 Repeater Panel
E.2.2 Compatibility
Zetron Model 38 Repeater Panel is compatible for all versions of MTR3000 Software and Hardware.
