MTR3000 Backplane: Basic Troubleshooting 6-27
To replace the fuse for failure, perform the following steps:
1. Turn off the base station/repeater power at source (e.g. AC breaker).
2. Remove fuse cover plate located on the backplane interface board shield by unscrewing one
M4 screw.
3. Pull defective fuse carefully with a pair of small needle nose pliers.
4. Replace new fuse (6583049X16) carefully with a pair of small needle nose pliers.
5. Restore power to the base station/repeater.
For continued protection of the base station/repeater against risk of fire,
replace the fuse only with the same type and rating of fuse.
C a u t i o n
