Motorola MTS 2000 - Page 12

Snohomish County PUD Radio Operations Manual • Rev. 6/03
6
Section I
7. Answer All Button
side button 1 (blue)
8. Page Button
side button 2
9. Telephone Button
side button 3
10. Push-To-Talk
(PTT) Switch
11. Display
16. Keypad
1. On / Off / Volume Control
2. Talkgroup Selector Knob
14. Universal
Connector
12. Microphone
15. Noise-
cancelling
port
6. Emergency Button
(orange)
[three-position (ABC)
toggle switch]
(two-position concentric switch)
5. Indicator LED
A
B
C
12 3
456
789
0
#
*
HOME
ABC
DEF
GHI JKL MNO
PRS TUV WXY
3. Scan ON/OFF
4. Zone Selection Switch
13. Speaker
TOP VIEW
