Wi-Fi Mirroring
Wi-Fi Mirroring lets you copy the traffic of wireless traffic for analysis and troubleshooting purposes. Click
Wi-Fi Mirroring under Diagnostics > Tools > Wi-Fi Tools in the function tree to access this screen.
Configure the following settings.
Mirroring Type
Setting
Description
Factory Default
Local
Select Local to mirror traffic to the local storage on the device.
None
Remote
Select Remote to have the AWK act as a server to be used
with capturing tool such as Wireshark to capture the mirror
traffic.
Mirroring Period (Local Type only)
Setting
Description
Factory Default
1 to 60 (min.)
Specify how long the device will mirror wireless traffic.
None
When finished, click START to start mirroring, and STOP to stop mirroring.
The result of the mirroring will be shown below. If you selected Local as the mirroring type, click
DOWNLOAD to download the result to your local machine.
RSSI Reporting
RSSI Reporting sends out the AP's SNR or detected Signal Strength over Syslog to a designated recipient
host for monitoring. This data is used to analyze if the configured Turbo Roaming Threshold and Roaming
Difference values are suitable for the current network environment. Click RSSI Reporting under
Diagnostics > Tools > Wi-Fi Tools in the function tree to access this screen.
