Moxa Technologies AWK Series User Manual

AWK Series User Manual
133
Ping
The Ping function is used to check the connection to a remote host. Click Ping under Diagnostics > Tools
in the function tree to access this screen.
Configure the following settings:
Target
Setting Description Factory Default
IP address/hostname
Enter the IP address or hostname you want to ping.
None
Ping Interval
Setting
Description
Factory Default
1 to 30 (sec.) Specify the interval at which the AWK will ping the host. 1
Stop Method
Setting Description Factory Default
Rounds
Specify Rounds as the stop method.
Rounds
Timestamps Specify Timestamps as the stop method.
Rounds (for Rounds Method only)
Setting Description Factory Default
3 to 86400
Specify the round value.
3
End Date (for Timestamps Method only)
Setting
Description
Factory Default
Date
Specify the date when to stop pinging the IP address or
hostname.
None
End Time (for Timestamps Method only)
Setting
Description
Factory Default
Time
Specify the time to stop pinging the IP address or hostname.
01:00 AM
When finished, click PING to begin pinging, or STOP to send.
Setup Wizard
The Setup Wizard allows users to perform basic device configurations to get the AWK running quickly.
Click Setup Wizard in the function tree to start the Wizard, then follow the on-screen instructions. There
are three configuration tabs: Wi-Fi Basic, Wi-Fi Security, and System. While the Wizard will start from
the Wi-Fi Basic section by default, you can go to any other tab at any time.
