AWK Series User Manual
100
If the default action is set to Accept and all rules are disabled, all packets will be denied.
Source MAC Address
Setting
Description
Factory Default
MAC address
Enter the source MAC address.
Any
Destination MAC Address
Setting
Description
Factory Default
MAC address
Enter the destination MAC address.
Any
When finished, click APPLY.
Layer 3 Policy
From the Layer 3 Policy screen, you can manage the L3 firewall policy and create, edit, and delete policy
rules. Click Layer 3 Policy under Firewall in the function tree to access this screen.
Configure the following settings.
Layer 3 Firewall Status
Setting
Description
Factory Default
Enabled/Disabled
Enable or disable the Layer 3 firewall function.
Disabled
Default Action
Setting
Description
Factory Default
Accept
Packets that match the policy rule will be allowed.
Drop
Drop
Packets that match the policy rule will be denied.
ATTENTION
Be careful when configuring the packet filtering function:
If the default action is set to Drop and all rules are disabled, all packets will be allowed.
If the default action is set to Accept and all rules are disabled, all packets will be denied.
When finished, click APPLY.
