AWK Series User Manual
95
Protocol (PAT Mode only)
Setting
Description
Factory Default
TCP/UDP
Specify the protocol.
TCP, UDP
WAN
Setting
Description
Factory Default
IP address
For 1-to-1 mode only. Specify the IP address for the WAN.
None
0 to 65535
For PAT mode only. Specify the TCP or UDP port number for
the WAN.
None
LAN
Setting
Description
Factory Default
IP address
Specify the LAN IP address.
None
0 to 65535
For PAT mode only. Specify the LAN TCP or UDP port number.
None
Click APPLY to create the new NAT rule.
For 1 to 1 NAT Mode and PAT Mode, refer to the following figure illustrations.
