HYDROCAL 1001+ Installation and operation manual Page 55/76
IV - Test Gas high alarm
Step
Description
Relay-
contact
c
-
White color / contact open
X2:1/2
1 x
1 of 2
Red color / contact open
X2:1/2
1 x
5 x
2 of 2
Green color / contact closed
X2:1/2
1 x
5 x
d
IV - Test Gas high-high alarm
Step
Description
Relay-
contact
d
-
White color / contact open
X2:3/4
1 x
1 of 2
Red color / contact open
X2:3/4
1 x
5 x
2 of 2
Green color / contact closed
X2:3/4
1 x
5 x
e
V - Test Moisture alarm
Step
Description
Relay-
contact
e
-
White color / contact open
X2:5/6
1 x
1 of 2
Red color / contact open
X2:5/6
1 x
5 x
2 of 2
Green color / contact closed
X2:5/6
1 x
5 x
End
VI - Return to normal operation
Note: The test mode is also terminated automatically 15 minutes after the last button operation. To
terminate the test mode prior press and hold both buttons until 1+3 beeps have occurred.
PRESS & HOLD RELEASE
