Machine layout
The following illustration uses the MFX-1950.
All illustrations used in this manual are of the MFX-
1950 unless otherwise noted.
LINE
PHONE1
PHONE2
LINE
PHONE1
PHONE2
Bypass tray
Automatic
document feeder
(ADF)
Control panel
Paper cassette
2nd paper cassette
(Option)
1st side cover
2nd side cover
Front co
ver
Paper le
vel
Indicator
Document
guides
Document
tray
Document
exit tra
y
Document glass
Po
wer switc
h
AC
power jack
T
elephone
Connectors
Platen cover
Paper e
xit tray
Second phone line
(Option)
Network connector
(Option)
USB connector
The document glass
is
av
ailable only
fo
r
the MFX-1950.
