Setting up the machine
Unlocking the mirror carriage
IMPORTANT: Do not turn the power on until after you have unlocked the scanner unit. Doing so
could damage the machine.
NOTE: This procedure is required only for MFX-1950.
1
Slide the scanner unit lock switch to the unlock position as shown below.
2
After you have unlocked the scanner unit, turn the transport mode off. (See page 1-11.)
Attaching the document tray
Attach the document tray by inserting it into the appropriate holes, as shown below.
