PROFINET IO
User manual 57106_hdb_en_13 70 / 94
Auto-Acknowledge = 1 (default)
 With Auto-Acknowledge = 1 each interrupt is acknowledged by the PROF-
INET device itself.
 In this mode the diagnostic data are overwritten by the new interrupts.
HINT
Activate the Auto-Acknowledge for the continuous use.
Data format
Motorola/Intel
This parameter is only analyzed when analog modules are used; it defines
how a value is stored in the CPU addressing range.
Motorola format
In Motorola format (default), the bytes are stored in decreasing order, i.e. the
first byte is the high byte, the second byte the low byte.
Intel format
In Intel format, the order is inverted and the bytes stored in increasing order,
i.e. the first byte is the low byte, the second byte the high byte.
