PROFINET IO
User manual 57106_hdb_en_13 69 / 94
Parameter data
PROFINET IO device
Tab. 11-2: Parameter data
Diagnostic interrupt type Here you can define the structure of the diagnostic interrupt data. In case of
an error they are sent in the diagnosis telegram. You can retrieve them using
the default PROFINET index numbers.
 Manufacturer specific data:
You receive the data record DS 0x01 of the module diagnostic data.
 Channel-specific data:
You receive the data record DS 0x00 of the module diagnostic data.
Auto-Acknowledge Interrupt acknowledgements at Cube20S backplane bus:
Auto-Acknowledge = 0
 With Auto-Acknowledge = 0 you are responsible for the acknowledgement
yourself.
 You receive the data record DS 0x01 of the module diagnostic data.
 You will be informed about each interrupt.
 As long as an interrupt has not been acknowledged by the PROFINET
controller, further interrupts of the corresponding module are blocked.
Byte Bit 7 ... 0 Description Default
0 Bit 0 Process interrupt
0 = lock
1 = enable
0x00
Bit 1 Diagnostic interrupt
0 = lock
1 = enable
Bit 2 Diagnostic interrupt type
0 = manufacturer-specific data
1 = channel-specific data
Bit 3 Auto-Acknowledge
0 = lock
1 = enable
Bit 4 Reserved
Bit 5 Web server
0 = lock
1 = enable
Bit 6 Reserved
Bit 7 Data format
0 = Motorola
1 = Intel
1 ... 4 0x00 (fixed) 0x00
5 Bit 0 FMM: Activation
0 = lock
1 = enable
0x00
Bit 1 FMM: Automatic restart
0 = lock
1 = enable
Bit 7 ... 2 Reserved
6 0x00 (fixed) 0x00
