PROFINET IO
User manual 57106_hdb_en_13 68 / 94
Planning Procedure
1 | Design your PROFINET IO system.
2 | Start your planning tool with a new project.
3 | Plan a master system and create a new PROFINET IO subnet.
4 | Take the PROFINET IO device 57106 from the hardware catalog and drag
it onto the PROFINET IO master subnet.
5 | Specify in Properties / General of the PROFINET IO slave a PROFINET
IO address within the range between 1 and 125.
6 | Set this address at the address switch.
7 | Open the specific Murrelektronik Properties dialog in the slot overview and
parameterize the PROFINET IO slave.
8 | Embed the expansion modules from the hardware catalog.
9 | Parameterize the expansion modules if necessary.
10 |Transfer your project to the PLC.
