PROFINET IO
User manual 57106_hdb_en_13 88 / 94
11.10 Index overview
General information The I/O, parameter and diagnosis data are accessed by means of the index
numbers within one module. PROFINET combines the index numbers in rang-
es.
Tab. 11-15: Ranges for index numbers in PROFINET
Further information is given in the PROFINET Specification. Index is also re-
ferred to as data record in there.
Index numbers The supported index numbers are listed below.
Readable index num-
bers
(manufacturer specific)
Tab. 11-16: Readable index numbers (manufacturer specific)
Writable index numbers
(manufacturer specific)
Tab. 11-17: Writable index numbers (manufacturer-specific)
Number Index
0x0000 ... 0x7FFF Manufacturer specific index numbers
0x8000 ... 0xF7FF Default index numbers of PROFINET
Index Access Description
0x0000 IO device +
Cube20S modules
DS 0x00 diagnostic data
0x0001 DS 0x01 diagnostic data
0x007D All parameter data
0x007E DS 0x00 of the parameter data
0x007F IO device DS 0x01 of the parameter data
0x0080 ... 0x0090 DS 0x80 … DS 0x90 of the parameter data
0x8028 Input data of a subslot
0x8029 Output data of a subslot
0xAFF0 Cube20S modules I&M 0 (serial no., name, SW/HW version)
0xAFF1 I&M 1 (identification and installation loca-
tion)
0xAFF2 I&M 2 (installation date)
0xAFF3 I&M 3 (comment)
Index Access Description
0x0000 IO device +
Cube20S modules
Write DS 0x00 of the parameter data
0x0001 Write DS 0x01 of the parameter data
0x007D All parameter data
0x007E DS 0x00 diagnostic data
0x007F IO device FMM configuration
(see section 11.6 FMM - Free Module
Mapping, Seite 73)
0x007F Cube20S modules DS 0x01 of the parameter data
0x0080 ... 0x0090 DS 0x80 … DS 0x90 of the parameter data
0xAFF1 I&M 1 (identification and installation loca-
tion)
0xAFF2 I&M 2 (installation date)
0xAFF3 I&M 3 (comment)
