PROFINET IO
User manual 57106_hdb_en_13 87 / 94
Tab. 11-11: Identification data 0: index 0xAFF0
Maintenance data 1: IN-
DEX: 0xAFF1
Representation: R/W = read and write access
Tab. 11-12: Maintenance data 1: INDEX: 0xAFF1
Maintenance data 2: IN-
DEX: 0xAFF2
Representation: R/W = read and write access
Tab. 11-13: Maintenance data 2: Index: 0xAFF2
Maintenance data 3: IN-
DEX: 0xAFF3
Representation: R/W = read and write access
Tab. 11-14: Maintenance data 3: Index 0xAFF3
IM_SOFTWARE_REVISION R Firmware revision Firmware revision
- SWRevisionPrefix (1 Byte) V, R, P, U, T
- IM_SWRevision_Functional_ Enhance-
ment
(1 Byte) 0x00 ... 0xFF
- IM_SWRevision_Bug_Fix (1 Byte) 0x00 ... 0xFF
- IM_SWRevision_Internal_ Change (1 Byte) 0x00 ... 0xFF
IM_REVISION_COUNTER (2 Byte) 0x0000 for internal use
IM_PROFILE_ID (2 Byte) 0x0000 for internal use
IM_PROFILE_SPECIFIC_TYPE (2 Byte) 0x0005 for internal use
IM_VERSION R 0x0101 Version of the I&M data
(e.g. 0x0101 = version 1.1)
- IM_Version_Major (1 Byte)
- IM_Version_Minor (1 Byte)
IM_SUPPORTED R (2 bytes) 0x000E I&M1 ... I&M3
are available
I&M data Access Presetting Description
I&M data Access Presetting Description
IM_TAG_FUNCTION R/W (32 bytes) - Specification of a unique identi-
fication
IM_TAG_LOCATION R/W (22 bytes) - Specification of the installation
location
I&M data Access Presetting Description
IM_DATE R/W (16 bytes) - Specification of an input date
(YYYY-MM-DD HH:MM)
I&M data Access Presetting Description
IM_DESCRIPTOR R/W (54 bytes) - Specification of a comment
