10. TECHNICAL DATA
SPECIFICATIONS
- Rated voltage: 230Vac/115Vac (according to the
model).
- Max. mains voltage fluctuation: ±10%.
- Maximum current: 6A for the 230Vac version;10A for
the 115Vac version at 60KV 7mA.
- Frequency: 50/60Hz.
- Maximum power absorbed: 1,4KVA.
- Apparent line resistance: 0,5Ω(230Vac),
0,2Ω(115Vac).
- Fuses: 6.3A T for the 230Vac version; 10A T for the
115Vac version.
- Generator: constant potential type.
- High nominal voltage: 60 / 63 / 65KV.
- Maximum current: 6 / 7mA.
- Power requirements at 0.1 sec: 420W (60KV 7mA),
378W (63KV 6mA), 390W (65KV 6mA).
- Current reference time: 0.7 mAs (7mA – 0.1s) / 0.6
mAs (6mA – 0.1s).
- Focal spot:
RX DC Plus: 0.4mm.
RX DC eXTend: 0.7mm.
- Total filtration: 2.5mm Al @ 65KV.
- Half-value layer (HVL): >2mm Al @ 65KV.
- Leaked radiation: <0.25mGy / h at 1 metre from
focusing at 65KV 6mA,duty cycle 1:60.
- Ability to be reproduced: 0.05.
- Electrical classification: Class I - Type B, intermittent
service.
- Set exposure time: from 0.010 to 1.000 seconds.
- Accuracy of times indicated: ±10%.
- mGy display precision: ±30%.
WEIGHTS
- Weight of the unit with packaging: 38Kg (84lb) max.
- Weight of the x-ray device: 25kg (55lb).
- Weight of the hand-held control panel: 0,3kg (0.7 lb).
