9-2
9.1 Table of Specifica tions
9.1.1
General Specifications
Item Description
Ambient temperature 0 to +55 °C
Storage temperature -20 to +70 °C
Ambient humidity 30 to 85% RH (at 25 °C non-condensing)
Storage temperature 30 to 85% RH (at 25 °C non-condensing)
Vibration resistance 10 Hz to 55 Hz, 1 cycle/min, double amplitude of 0.75 mm
10 min on X, Y, Z axes
Shock resistance Shock of 98 m/s2 or more, 4 times on X, Y, Z axes
Noise immunity 1000 Vp-p with pulse widths 50 ns and 1ɱs (by noise simulator)
Operation condition Free from corrosive gases and excessive dust
Consumption current Approx. 480 mA
Weight (main unit) Approx. 130 g
Weight (communication block) Approx. 35 g
