3.2 Wiring of Commu nication Blocks
3.2.1
FP2-CB232(AFP2803), FP2-CB422(AFP2804)
D-sub connector and conector cover set comes with MCU.
Use the attached set or equivalent.
Accessories Manufacturer Product No.
D-sub connector J.S.T. Mfg Co.,Ltd Equivalent to JEZ-9P
Cover set J.S.T. Mfg Co.,Ltd Equivalent to J-C9-2C
Note1) When using any cover set other than the attached one, the cover set should be the one of which
width is 35 mm or less in order to avoid the interference with the connector cover of the COM. 1 and
COM. 2.
Note2) When using the attached cover set, the cable diameter should be 7 mm or less.
