NAiS FP2 - Restrictions on Units Combination; Restrictions on Installation Position and Number of Units

1-5
1.3 Restrictions on U nits Combination
1.3.1
Restrictions on Installation position and Number of Units
Mode Specifications
PC(PLC) link
When using FP2:
Install within three units in combination with W link, CCU and MCU.
When using FP2SH:
Install two units within five units in combination with W link, CCU and
MCU. *2
When using both FP2/FP2SH:
Up to two units, including W link mode set to PC (PLC link) mode, can
be used. *1
General-purpose serial
communication
Can be installed in any position.
Computer link Can be used up to eighth MCU.
Note:
The restrictions are not related to the number of channels for each unit.
(Either COM.1 port and COM.2 port is counted as one unit in case of the CCU setting.)
