High- level Instructions
9-14
Outline Data is transmitted to external equipment via the COM port of the
specified MCU.
This function is available from FP2/FP2SH Ver. 1.50 or later.
Program example
Ladder
Diagram
Boolean
Ladder Diagram
Address Instruction
Trigger
S n
10
X4
F159 MTRN, DT 0, K 10, H C1
1
1
DF
D
10
11
12
ST X 4
DF
F159 (MTRN)
DT 0
K10
HC1
S
Head area of the data table
n
Area or constant data in which the byte number of the transmitted data stored
- When it is positive value, the terminal code is added in transmission.
- When it is negative value, the terminal code is not added in trasmission.
- In case of H8000, the application of the MCU port specified in transmission is
changed.
D
Specification of the slot number and port number of the MCU unit which the
data is transmitted.
Operands
Operand
Relay Timer/Counter Register
Index
register
Constant
Index
Operand
WX WY WR WL SV EV DT LD FL
I
(*1)
K H
Index
modifier
S
A A A A A A A A A A N/A N/A A
n
A A A A A A A A A A A A A
D
N/A A A A A A A A A A A A A
(*1) I0 to ID.
FP2/FP2SH
P159
(PMTRN)
Serial data communication
(for MCU COM port)
Availability
FP2/FP2SH
(MTRN)
F159
A: Available
N/A: Not Available
