Napoleon Ascent X Series Installation Manual

EN
W415-1794 / 06.28.18
9
general information
1.5 hardware list
Ref. # Description Quantity
1
Self-drilling screw 2
2
1/4” Hex, 1/2” long sheet metal screw 18
3
2 1/2” long sheet metal screw 4
4
Quad drive sheet metal screw 4
5
Sheet metal screw 4
6
Pan head quad screw 4
Only fasteners supplied with the appliance will be illustrated.
note:
1.6 front frame installation
2
3
4 5
1
5
Install the front frame using 6 screws
(supplied).
The front frame must be installed.
note:
#2 X6
