SECTION3–INSTRUMENTS,INDICATORS,ANDSWITCHES

OilPressureGauge(cont.)

LubricationOilPressure

LubeOilPressure

Atnormaloperatingtemperature

Lowidle12psi(83kPa)min.

Highidle45psi(310kPa)

CAUTION:Topreventenginedamage,shutdownengine

immediatelyiftheoilpressureindicatorlampandalarmare

active.

EngineExhaustBrakeOn/OffToggleSwitch

Figure23ExhaustBrakeToggleSwitch

Theexhaustbraketoggleswitchturnstheengineexhaustbrake

ONorOFF.

Page46
