SECTION5–MAINTENANCESCHEDULEANDSERVICEPROCEDURES
ServiceProcedures(cont.)
FUELWATERSEPARATOR
ServiceInterval:WithOilChangeorWhenWaterInFuelSensor
LightIlluminates
Figure29WaterDrainValve
1.Primaryfuellter
2.Oillevelgauge
3.Secondaryfuellter
4.Fuelcooler
5.Waterdrainvalve
GOVERNMENTREGULATION:Engineuids
(oil,fuel,andcoolant)maybeahazardtohuman
healthandtheenvironment.Handlealluidsand
othercontaminatedmaterials(e.g.lters,rags)in
accordancewithapplicableregulations.Recycle
ordisposeofengineuids,lters,andother
contaminatedmaterialsaccordingtoapplicable
regulations.
WARNING:Topreventpersonalinjuryordeath,donot
smokeandkeepfuelawayfromamesandsparks.
WARNING:Topreventpersonalinjuryordeath,store
dieselfuelproperlyinanapprovedcontainerdesignedfor
andclearlymarkedDIESELFUEL.
1.Ifthedesiredcollectioncontainerwillnottunderthewater
drainvalve,connectahosetotheendofthewaterdrain
valve.
2.Putasuitablecontainerunderwaterdrainvalve(ordrain
hose).
Page71
