30
Key Table Chart
Value Key Name Value Key Name
64 Enter 96 Assign Loco to Cab
65 Program 97 Program on Main
66 Recall 98 Set Clock
67 Direction Toggle 99 Use program track
68 Setup consist 100 Setup command station
69 Add loco to consist 101 Setup Procab
70 Delete loco from consist 102 Setup macros
71 Kill consist 103 Setup old consist
72 Select loco 104 Setup advanced consist
73 Horn/Whistle 105 Display F1-F28 status
74 1 Speed step faster 106 Forward
75 1 Speed step slower 107 Reverse
76 Emergency Stop 108 Select Signal
77 Bell 109 Reserved
78 Select Accessory 110 Reserved
79 Expn (Expansion) key 111 Momentum
80 Headlight, Zero key 112 F10
81 F1, number 1 key 113 F11
82 F2, number 2 key 114 F12
83 F3, number 3 key 115 Reserved
84 F4, number 4 key 116 Reserved
85 F5, number 5 key 117 Reserved
86 F6, number 6 key 118 Reserved
87 F7, number 7 key 119 Reserved
88 F8, number 8 key 120 Reserved
89 F9, number 9 key 121 Reserved
90 4/10 speed steps faster 122 F10-F28 Status
91 4/10 speed steps slower 123 Reserved
92 Macro 124 Reserved
93 28/128 select 125 “no key” pressed
94 Brake (factory setting) 126 Reserved
95 Do not use 127 do not use
ProCab Specifications:
Size: 8-3/4 x 3-5/8” x 1”
Power Requirements: 8 VDC 40mA (backlight off)
8 VDC 120mA (backlight on)
Replacement Encoder: Bournes or Digikey part #3315C-1-006L
Speed control: Thumbwheel operated digital encoder with adjustable ballistic
tracking rate. Pushbutton speed control with adjustable auto-repeat rate (4
pulses per second to one pulse per 4 seconds).
Backlit LCD Display: 2 line by 16 characters/line. Two extra display lines
available for display of additional information when used with computer
dispatcher programs.
