CONSIST ADDRESS:
The consist address can be any number from 1 through 127. The system will suggest the
first available consist address (the priority is highest to lowest). Press enter to accept this
address.
SETUP 2:00PMSETUP 2:00PM
SETUP 2:00PMSETUP 2:00PM
SETUP 2:00PM
CON ADDR: 127CON ADDR: 127
CON ADDR: 127CON ADDR: 127
CON ADDR: 127
You may enter any other number you wish then press the ENTER key. If you have
locomotives on the layout using short addresses make sure you don’t pick an address
already in use. This is one reason to use long addresses with your loco fleet. It will keep
the short addresses free for consists.
ENTERING THE LEAD LOCO NUMBER
Entering the lead loco number is optional but recommended. The command station
keeps track of consists by their lead loco number. The locomotive is the loco that the
command station will send function commands to. For example: headlight on/off
commands. If the command station did not know the lead loco it would not know which
locomotive should have the headlight turned on or off.
The lead loco number also acts as an alias for the consist number entered above. Say
you have a bunch of consists stored on staging tracks and you wish to operate one of
them. After the consist is set up, you can select the consist by pressing SEL LOCO then
entering either the lead loco number or the consist number. The lead loco number is
typically easiest to remember because it is the number printed right on the locomotive.
The consist address may not relate to any visible or easily remembered number.
SETUP 2:00PMSETUP 2:00PM
SETUP 2:00PMSETUP 2:00PM
SETUP 2:00PM
LEAD LOCO: _LEAD LOCO: _
LEAD LOCO: _LEAD LOCO: _
LEAD LOCO: _
Enter the lead loco number followed by pressing the ENTER key.
ENTERING THE LEAD LOCO DIRECTION
If the locomotive is to operate in the forward direction press ENTER. Press the
DIRECTION key if you wish to have the locomotive operate in the reverse direction.
Subsequent presses of the DIRECTION key will keep changing the direction. When you
get the direction you desire press the ENTER key.
CONSIST 2:00PMCONSIST 2:00PM
CONSIST 2:00PMCONSIST 2:00PM
CONSIST 2:00PM
DIR THIS LOCO: FDIR THIS LOCO: F
DIR THIS LOCO: FDIR THIS LOCO: F
DIR THIS LOCO: F
This informs the decoder if the loco is in the line-up facing forward or reverse. For
instance, in an A-B-A consist the lead A unit and the B unit will be setup in the Forward
direction, and the second A unit will be setup in the Reverse direction.
ENTERING THE REAR LOCO NUMBER
Entering the rear loco number is optional. The command station keeps track of consists
by their lead or rear loco number. If you select the consist by the rear loco number the
direction of the consist will be reversed from the direction of operation if you selected it
by the lead loco. You don’t have to enter a rear loco number if you don’t need/want to
operate the consist in reverse. The rear loco number also act as an alias for the consist
number just as the lead loco number.
SETUP 2:00PMSETUP 2:00PM
SETUP 2:00PMSETUP 2:00PM
SETUP 2:00PM
REAR LOCO: _REAR LOCO: _
REAR LOCO: _REAR LOCO: _
REAR LOCO: _
Enter the rear loco number followed by the ENTER key.
