ENTERING THE DECODER (LOCOMOTIVE)
ADDRESS
The short address is displayed first. If you wish to change it type in the new address and
press ENTER. If you wish to keep it unmodified just press ENTER to skip to the display
of the long address.
ACTIVE ADR:SHORTACTIVE ADR:SHORT
ACTIVE ADR:SHORTACTIVE ADR:SHORT
ACTIVE ADR:SHORT
SHORT ADDR: 003SHORT ADDR: 003
SHORT ADDR: 003SHORT ADDR: 003
SHORT ADDR: 003
If you put in a new address you will see the following LCD screen asking if you wish to
make this address the primary address. Only one address can be the primary address –
the long or the short. You cannot have both active at the same time. The decoder will
not allow it.
The long address is displayed next. If you wish to change it type in the new address and
press ENTER. If you wish to keep it unmodified just press ENTER to skip to continue
programming.
SETUP ADDRESSSETUP ADDRESS
SETUP ADDRESSSETUP ADDRESS
SETUP ADDRESS
LONG ADDR: 1044LONG ADDR: 1044
LONG ADDR: 1044LONG ADDR: 1044
LONG ADDR: 1044
If you enter a new long address you will be asked if you want to activate it. Press 1 for
yes. Any other key continues with programming.
ACTIVATEACTIVATE
ACTIVATEACTIVATE
ACTIVATE
THIS ADDR: 1=YESTHIS ADDR: 1=YES
THIS ADDR: 1=YESTHIS ADDR: 1=YES
THIS ADDR: 1=YES
NOTES ON ADDRESSES:
The short address is available for use on layouts using short addresses. If the short
address is to be the primary address you should use the last two digits of the loco
number. Short addresses range from 1 to 127.
For the long address, any number from 0 through 9999 can be used. You need to
distinguish long addresses from short when assigning an address below 128 by entering
a zero as the first character.
Example: short address = 64
long address (below 128) = 064
We recommend that if a long address is used, leave the short address at 3. This has two
advantages. One, if the long address is forgotten, the short address is always 3. Two,
advanced consist addresses share the same 1 to 127 address range available to the
short addresses. Using the same address for an Advanced Consist and another existing
loco will cause unpredictable results.
SETTING UP BASIC DECODER CONFIGURATION (CV29)
This option will setup various decoder configuration parameters. There are six of these
parameters squeezed into one CV. Press 1 if you want to set these parameters. Any
other key will skip to Motor Control Setup.
SET CFG?SET CFG?
SET CFG?SET CFG?
SET CFG?
ENTER=NO 1=YESENTER=NO 1=YES
ENTER=NO 1=YESENTER=NO 1=YES
ENTER=NO 1=YES
You will be asked a series of questions regarding the basic operation of the locomotive.
If you are in doubt about the proper answer just press enter and you will usually be OK.
DIRECTION BIT - NORMAL OR REVERSE
Press ENTER for the locomotive to operate in the normal direction or press 1 to switch
the direction of operation.
