F2 12345678F2 12345678
F2 12345678F2 12345678
F2 12345678
OUTPUTS: —4——OUTPUTS: —4——
OUTPUTS: —4——OUTPUTS: —4——
OUTPUTS: —4——
Pressing a digit key will enable the output on the decoder when the function is activated.
Pressing the same digit key again will disable the output. In the display above the 4 key
has been pressed so that output number 4 will activate when ever the F2 button is
pressed on your handheld cab. If you were to press another digit such a 6, both output
4 and output 6 will be controlled by pressing F2.
When mapping functions higher than 3, the top line of the LCD will use small numbers to
indicate the output numbers 10 through 14. To enable/disable these high numbers press
the digit key that is 10 less than the output number. Example: press 0 for output 10, 1
for output 11, etc. Pressing PROG/ESC will exit from mapping at any time.
SETUP NCE LIGHTING EFFECTS (Option 6)
You can use this option to customize the lighting effects for your NCE decoder equipped
locomotives. This programming option will only work with NCE decoders.
NCE EFX 07:04NCE EFX 07:04
NCE EFX 07:04NCE EFX 07:04
NCE EFX 07:04
OUTPUTNUMBER: _OUTPUTNUMBER: _
OUTPUTNUMBER: _OUTPUTNUMBER: _
OUTPUTNUMBER: _
Function outputs are numbered from 1 to 14. Do not confuse Output numbers with
Function numbers. The headlight is always output 1 and the reverse light is usually
output 2. You are prompted for the output number to setup. Press the output number
followed by ENTER.
OUTPUT NUMBER:03OUTPUT NUMBER:03
OUTPUT NUMBER:03OUTPUT NUMBER:03
OUTPUT NUMBER:03
USE THUMBWHEEL USE THUMBWHEEL
USE THUMBWHEEL USE THUMBWHEEL
USE THUMBWHEEL
Use the thumbwheel or up/down speed buttons to scroll through the different lighting
effect options. Press ENTER when you get the one you want.
DIR OF OPERATIONDIR OF OPERATION
DIR OF OPERATIONDIR OF OPERATION
DIR OF OPERATION
1=FW 2=RV 3=BOTH1=FW 2=RV 3=BOTH
1=FW 2=RV 3=BOTH1=FW 2=RV 3=BOTH
1=FW 2=RV 3=BOTH
Next press 1,2 or 3 to select the ‘directionality’ of the output. If you want the output
active only in the forward direction of travel - press 1. Press 2 for the effect to operate
only when travelling in reverse. 3 activates the output no matter which direction the
locomotive is travelling.
REGULAR BULB ORREGULAR BULB OR
REGULAR BULB ORREGULAR BULB OR
REGULAR BULB OR
LED 1=BULB 2=LEDLED 1=BULB 2=LED
LED 1=BULB 2=LEDLED 1=BULB 2=LED
LED 1=BULB 2=LED
Last, press 1 if the output has a regular incandescent bulb attached. Press 2 if the output
has an LED connected. LEDs behave differently when dimmed than incandescent bulbs.
Pressing 1 or 2 informs the decoder which set of lighting characteristics to use for this output.
QSI PROGRAMMING (Option 8)
QSI sound decoders use indexed programming of CV51,CV52,and CV56. You are
asked for an index number before you are asked for the CV value. CV49 is then
automatically set with the index value before the original CV is set with the desired data.
When programming CV56 you are asked for primary and secondary index numbers
before you are asked for the CV value. CV49 and CV50 are then automatically set with
the index numbers before CV53 is set with the desired data.
All other CV’s are programmed in the normal manner.
