68
EMERGENCY STOP LAYOUT SHUTDOWN
When you press the Emergency Stop button three times the layout power will be shut
down and the address of the cab that shutdown the layout is broadcast to all other
cabs. Only the cab that shut down the layout can start it up again by pressing ENTER.
The shutdown can be disabled. The factory default is enabled. Press ENTER to skip
setting this parameter.
ESTOP SHUTDOWNESTOP SHUTDOWN
ESTOP SHUTDOWNESTOP SHUTDOWN
ESTOP SHUTDOWN
ENABLE 1=Y 0=N 1ENABLE 1=Y 0=N 1
ENABLE 1=Y 0=N 1ENABLE 1=Y 0=N 1
ENABLE 1=Y 0=N 1
RADIO FIX ENABLE
If on, steps are taken in the command station to prevent runaways when using radio
cabs. The command station notices if speed buttons or a pot is being used on a cab by
cab basis. If speed buttons are in use a bit is set and any “full speed” pot commands
(the most common kind of erroneous radio command) are ignored thus preventing most
runaways.
RADIO FIXRADIO FIX
RADIO FIXRADIO FIX
RADIO FIX
ENABLE 1=Y 0=N 1ENABLE 1=Y 0=N 1
ENABLE 1=Y 0=N 1ENABLE 1=Y 0=N 1
ENABLE 1=Y 0=N 1
You may need to disable the “fix if you are using a CAB04e with both “halves” of the cab
set to the same cab address AND one half is set to yard mode while the other is set to
normal mode or the ProCab set to yard mode. If you have an older ProCab with a
potentiometer (1994-1997) you will probably have to disable this feature. It is on by
factory default. Press ENTER to skip setting this parameter.
AIU BROADCAST ENABLE
The system can be set to have any connected AIU (Auxiliary Input Unit) automatically
outputs its status via the RS232 port on the system box whenever an AIU input
changes. This is disabled by default. Press ENTER to skip setting this parameter.
AIU BROADCASTAIU BROADCAST
AIU BROADCASTAIU BROADCAST
AIU BROADCAST
ENABLE 1=Y 0=N 0ENABLE 1=Y 0=N 0
ENABLE 1=Y 0=N 0ENABLE 1=Y 0=N 0
ENABLE 1=Y 0=N 0
RS232 PORT BAUD RATE
You can set the system box RS-232 Baud Rate to 9600, 19,200 or 38,400 bits per
second. Press the appropriate number to select the baud rate you desire. Factory
default is 9600. Press ENTER to skip setting this parameter.
BAUD RATE 1=9600BAUD RATE 1=9600
BAUD RATE 1=9600BAUD RATE 1=9600
BAUD RATE 1=9600
2=19.2 3=38.4 12=19.2 3=38.4 1
2=19.2 3=38.4 12=19.2 3=38.4 1
2=19.2 3=38.4 1
RESET SYSTEM
Selecting this option will reset the system box back to original factory settings. You are
asked to press 2 different buttons to make sure you really want to reset. All consist,
macros and system set up parameters will be lost. Press ENTER to skip setting this
parameter.
RESET SYSTEM?RESET SYSTEM?
RESET SYSTEM?RESET SYSTEM?
RESET SYSTEM?
PRESS 6 FOR YESPRESS 6 FOR YES
PRESS 6 FOR YESPRESS 6 FOR YES
PRESS 6 FOR YES
FUNCTION REFRESH
This parameter enables Function (F0-F12) commands to be repeated on the rails after
the “normal” number (TEMP PKTS… see TEMP PKTS above) of commands are sent. If
non-zero, Function Group 1, Function Group 2 and Function Group 3 commands are
