Enter the new address for the locomotive. The new address will be sent to the
locomotive and you will be returned to the normal display with the locomotive selected
and ready to run. Most decoders allow programming the address while on the mainline. If
you are using a locomotive with a sound decoder from QSI you will need to turn off
verbal programming acknowledgment (set CV62 to 0) for the address to be set properly.
If your locomotive does not allow setting the address on the mainline you will need to set
it on the programming track. You can press PROG/ESC to escape out of setting the
address without affecting anything in the decoder. No commands are sent until you
press ENTER after typing in the address.
CV PROGRAMMING (Option 2)
This option allows you to change any configuration variable (range of 1-999) in your
decoder.
ENTER CONFIGURATION VARIABLE NUMBER
All configuration variables can be set while on the mainline. Just pressing ENTER without
typing in a number will return you to the main OPS programming prompt. Pressing
PROG/ESC will completely exit from programming and return you to the normal display.
PROG CV 02:00PMPROG CV 02:00PM
PROG CV 02:00PMPROG CV 02:00PM
PROG CV 02:00PM
ENTER CV NUM: _ENTER CV NUM: _
ENTER CV NUM: _ENTER CV NUM: _
ENTER CV NUM: _
ENTER THE VALUE
The value to be programmed into the CV should now be entered at the prompt below.
Pressing PROG/ESC before or during number entry will completely exit from programming
and return you to the normal display.
PROG CV 02:00PMPROG CV 02:00PM
PROG CV 02:00PMPROG CV 02:00PM
PROG CV 02:00PM
ENTER VALUE: _ENTER VALUE: _
ENTER VALUE: _ENTER VALUE: _
ENTER VALUE: _
SET DECODER CONFIGURATION (Option 3)
This option will setup the various decoder configuration parameters. There are six of
these parameters squeezed into one CV. You will be asked a series of questions
regarding the basic operation of the locomotive. If you are in doubt about the proper
answer just press ENTER and you will usually be OK.
DIRECTION BIT - NORMAL OR REVERSE
Press ENTER for the locomotive to operate in the normal direction or press 1 to switch
the direction of operation.
DIR BIT? 02:00PMDIR BIT? 02:00PM
DIR BIT? 02:00PMDIR BIT? 02:00PM
DIR BIT? 02:00PM
ENTER=NORM 1=REVENTER=NORM 1=REV
ENTER=NORM 1=REVENTER=NORM 1=REV
ENTER=NORM 1=REV
SPEED STEPS - 28 OR 14
Press ENTER. All decoders made since 1997 support 28 speeds. NOTE: If you are
wondering how to set the decoder for 128 speed operation, you do not have to program
anything. 128 speed mode is always enabled in decoders that support 128 speed step
operation.
SPEED 02:00PMSPEED 02:00PM
SPEED 02:00PMSPEED 02:00PM
SPEED 02:00PM
ENTER=28 1=14 _ENTER=28 1=14 _
ENTER=28 1=14 _ENTER=28 1=14 _
ENTER=28 1=14 _
