BINARY COMMAND SET
The RS-232 port binary commands are designed to work in a computer friendly way.
Command format is: <command number> <data> <data> ...
Commands range from 0x80 to 0xBF
Commands and formats supported:
Commands 0xAD to 0xBF are not used and return ‘0’
Errors returned:
‘0’= command not supported
’1'= loco address out of range
’2'= cab address out of range
’3'= data out of range
’4'= byte count out of range
’!’= command completed successfully
For a complete description of Binary Commands see: www.ncecorporation.com/pdf/
bincmds.pdf
