4-16
TROUBLESHOOTING
DLP CommE Fail
Yes
No
Is there any abnormality between the CPU PWB
and the ETHER PWB, such as drawing out of the
LAN connector?
Adjust the faulty spots.
Yes
No
Is there any abnormality between the ETHER PWB
and the MOTHER PWB, such as drawing out of
the LAN connector?
Adjust the faulty spots.
Adjust the faulty spots.
Yes
No
Is there any abnormality between the ETHER PWB
and the PJDIV PWB, such as drawing out of the
connector?
Follow the steps of replacement work in the order
specified below.
ETHER PWB
PJDIV PWB
CPU PWB
INTERFACE board
