2. Installation and Connection
19
2-3. Connecting the various control terminal
For control, your projector comes with such ports as the PC control terminal and the Ethernet port (RJ-45).
• PC control terminal (PC CONTROL) ----- Use this terminal when controlling the projector in serial connection from a PC.
• Ethernet port (LAN 1/LAN 2) --------------- Use this port when controlling the projector in LAN connection from a PC.
SDI-A
SDI-B
DVI-A
DVI-B
GP I/O
LAN-A
LAN-B
REMOTE
IN
RS-232C
PC CARD
USB
CINEMA
SYSTEM
RS-232C
Ethernet cable
