NEC NC1600C - Connecting Image Input Terminals

2. Installation and Connection
18
2-2. Connecting the image input terminals
Your projector has four image input terminals, namely, the HDSDI A input terminal, the HDSDI B input terminal, the DVI-D A
input terminal, and the DVI-D B input terminal.
• HDSDI A/B input terminal (SDI A/SDI B) ------------ Inputs serial digital images from a Video Server or Video source.
• DVI-D A/B input terminal (DVI A/DVI B) ------------- Inputs digital RGB signals from a PC.
SDI-A
SDI-B
DVI-A
DVI-B
GP I/O
LAN-A
LAN-B
REMOTE
IN
RS-232C
PC CARD
USB
CINEMA
SYSTEM
75Ω coaxial cable DVI-D signal cable
