NEC NC1600C - Replacement Part List

“Confidential, Do Not Duplicate without written authorization from NEC.”
11-1
REPLACEMENT PART LIST
SPARE PARTS PRICE LIST WITH NEW PARTS MARKING.
Model Name:NC1600C
(Product Code:01154041)
"N"mark means new part to previous.
ITEM N PART NO. DESCRIPTION REMARK
1 12JS0271 COLD MIRROR
2N 12JT1791 UV GLASS(PA67)
3N 12JT2301 REFLECTOR(PA67)
4N 24BS7771 OPT ENGINE(PA67)
5N 24BS7781 WATER COOLED UNIT(PA67)
6N 24BS7791 LENS MOUNT(PA67)
7N 24BS7841 HANDLE
8 24C02841 CABLE CLIP(FCA-10)
9 24C05331 GASKET(STG1-7)
10 24C05351 GASKET(STG10-10)
11 24C06051 GASKET(STG2-10)
12 24C06081 GASKET(STG15-10)
13 N 24C07471 OMEGA LOCK(OLS-80)
14 24C07561 GASKET(STG0.5-8)
15 24C07621 PLUNGER(PH-48)
16 24C08271 SPRING(ST-7(TG))
17 24C08381 STRAP(1K-57)
18 24C08391 WASHER(TM-137-2)
19 24C08421 GUARD(FAN)(80)
20 24C08441 GASKET(STG3-5)
21 24C08591 GASKET(STG7-10)
22 24C08871 BALL LOCK PIN(BJ775-0804)
23 24C08881 FOOT(RP-70M14)
24 24C08991 DUST CAP(USB)
25 24C09011 DUST CAP(D-SUB 9)
26 24C09021 DUST CAP(D-SUB 15)
27 24C09031 DUST CAP(D-SUB 37)
28 N 24C09131 KEY(TL-96L)
29 N 24C09141 CUSHION
30 N 24C09311 GASKET(STG1-5)
31 N 24D14151 FRONT PANEL C
32 N 24D14161 FRONT PANEL D
33 N 24D14171 FRONT PANEL E
34 24FT8872 PC-DUMMY-CARD WT
35 24H56652 SHIELD PLATE(FRONT)
36 N 24H61071 CAM(LOCK)TI
37 24HS3981 BRACKET(FA)ASSY
38 24HS3991 BRACKET(FB)ASSY
39 24HS4011 BRACKET(FD)ASSY
40 24HS4041 BRACKET(FF)ASSY
41 N 24HS4401 BRACKET(FB)B ASSY
42 N 24HS4411 BRACKET(FE)B ASSY
43 24J25081 CAP
44 24J28381 FILTER A
45 24J28391 FILTER B
46 24J29571 GASKET(USB)
47 24J30881 CUSHION(30*18*T5)
