REPLACEMENT PART LIST
48 N 24K26381 DIFFUSER
49 24L49921 LABEL(HEAT)
50 24L62591 CAUTION LABEL(LAMP)
51 N 24L63652 INSTRUCTION NAME PLATE
52 24N08071 SCR(TL-243-2)
53 N 24N08431 SPECIAL SCREW(M4*18)
54 24P04471 FRONT PANEL F
55 N 24P05481 COVER(REAR PANEL)
56 N 24P05491 FILTER CASE(REAR)
57 N 24PS5241 FRONT PANEL A ASSY
58 N 24PS5251 TOP COVER F ASSY
59 N 24PS5261 TOP COVER R ASSY
60 N 24PS5271 SIDE PANEL LF ASSY
61 N 24PS5281 SIDE PANEL LR ASSY
62 N 24PS5291 SIDE PANEL RF ASSY
63 N 24PS5301 SIDE PANEL RR ASSY
64 N 24PS5311 REAR PANEL A ASSY
65 N 24PS5321 REAR PANEL B ASSY
66 N 24PS5331 DUCT(TOP)ASSY
67 N 24PS5341 SIDE PANEL RF(CABLE)ASSY
68 24V00111 SCREW,PL-CPIMS*3*8*3GF
69 24V00661 PIWA*4*3GF
70 3N100921 POWER SUPPLY(LEB100F-0524
71 N 3N101231 POWER SUPPLY(AC6-2HECB-0
72 N 3N101241 POWER SUPPLY
73 N 3N101251 IGNITER SS-140GMNE
74 3N170096 DCFAN 2406KL
75 3N170098 DCFAN 4715KL
76 3N170100 DCFAN 9BAM24GD2-2
77 N 3N170122 DCFAN BL6771
78 N 3N170123 DCFAN 9G0824G1D03
79 7N520057 CABLE REMOTE CONTROL 16M
80 7N8P7491 PROJECTOR WARRANTY(SHEET)
81 N 7N8P7972 NC1600C IMPORTANT INFO
82 7N900124 REM-T HAND UNIT RD-371E
83 7N950851 INTERFACE 2506940-0002
84 7N950861 PROCESSOR 2506937-0002
85 N 7N951092 NC1600C MANUAL CD-ROM
86 81L07V01 DVI-OUT_PWB PWB ASSY
87 81L23CA3 CPU PWB ASSY
88 81L23CC3 SCAP PWB ASSY
89 81L23L01 LCD_MODULE ASSY
90 N 82N94121 PRISM ASSY
91 N 81N94B01 FSBB_PWB PWB ASSY
92 N 81N94F01 FFIB_PWB PWB ASSY
93 N 81N94M01 MOTHER_PWB PWB ASSY
94 N 81N94R01 FSBR_PWB PWB ASSY
95 N 81N94YA1 PJDIV PWB ASSY
96 N 81N94YB1 ETHER PWB ASSY
97 N 81N94YC1 GPIO PWB ASSY
98 N 81N94YD1 LIGHT1 PWB ASSY
99 N 81N94YE1 LIGHT2 PWB ASSY
100 N 81N94ZA1 PJKEY PWB ASSY
101 N 81N94ZAA TSENS-A PWB ASSY
102 N 81N94ZAB TSENS-B PWB ASSY
103 N 81N94ZAC TSENS-C PWB ASSY same board
104 N 81N94ZAD TSENS-D PWB ASSY
105 N 81N94ZAE TSENS-E PWB ASSY
106 N 81N94ZB1 AC PWB ASSY
