NEC NC1600C - Page 165

“Confidential, Do Not Duplicate without written authorization from NEC.”
7-2
ADJUSTMENTS AND INSPECTIONS ATTRIBUTABLE TO THE REPLECEMENT OF ELECTRICAL AND OPTICAL PARTS
Adjust item Version check for Firm & Data
Installation of Firm & Data 3. Writing into CPU Board
Inspection Confirm that video pictures can be seen. 7-15. Picture quality check Confirmation of image display 7-15. Picture quality check
Item Any input is acceptable. 7-15. Picture quality check Any input acceptable
3D check Operation check at each terminal on 7-18. Operation check for external control
CPU PWB terminals
Serial No. writing 7-21. Serial No. writing
7-22. Digital Cinema Certificate
Digital Certification Refer to data acquisition.
Adjust Item Adjustment of GPSU output 4. Output adjustment for General Power
Supply Unit (PJDIV PWB)
Inspection Confirmation of image display 7-15. Picture quality check Confirmation of image display 7-15. Picture quality check
Item Any input acceptable Any input acceptable
Touch panel power supply
7-19. Operation check for optional equipment MM2000B operation (images) 7-19. Operation check for optional equipment
Anamorphic turret operation 7-19. Operation check for optional equipment DVI input picture check 7-15. Picture quality check
Items for Reference Replacement of CPU PWB Items for Reference
Replacement of PJDIV Items for Reference Replacement of DVI-OUT Items for Reference
Replacement of Cables
(Signal lines between FFIB and FSB)
