ADJUSTMENTS AND INSPECTIONS ATTRIBUTABLE TO THE REPLECEMENT OF ELECTRICAL AND OPTICAL PARTS
4) After voltage check, turn the power OFF at the projector. Reinstall the Interface Board, the Processor Board,
and the EFIB Board, which have been disconnected before work.
Note) Record the measured values (voltages) at TP8003, TP8004, and TP8005.
Projector front-right side
