NEC NC1600C - SLED-A PWB (PWC-4692 E)

CONNECTION DIAGRAMS
“Confidential, Do Not Duplicate without written authorization from NEC.”
12-17
SLED-A PWB (PWC-4692E)
POST Connect to PJDIV PWB
1
2
3 Rear Status LED (Red) cathode (L : Light)
4 Rear Status LED (Green) cathode (L : Light)
5 GND
5V Standby for Rear Status LED (Red and Green)
POST1 Connect to SLED-B PWB
1
2
3 Rear Status LED (Red) cathode (L : Light)
4 Rear Status LED (Green) cathode (L : Light)
5V Standby for Rear Status LED (Red and Green)
