NEC NC1600C - FSD R;G PWB (PWC-4670)

CONNECTION DIAGRAMS
“Confidential, Do Not Duplicate without written authorization from NEC.”
12-27
POJ1 Connect to FFIB PWB
1 SAT_DATA_P0
2 SAT_DATA_P1
3 SAT_DATA_N0
4 SAT_DATA_N1
5 GND
6 SAT_DATA_P2
7 SAT_DATA_P3
8 SAT_DATA_N2
9 SAT_DATA_N3
10 GND
11 SAT_TXDATA_P
12 SAT_DIN
13 SAT_TXDATA_N
14 SAT_CCLK
15 SAT_CLK_P
16 GND
17 SAT_CLK_N
18 SPARE_LVDS0
19 SAT_PWRGOOD
20 SPARE_LVDS1
21 SAT_DONE
22 SAT_DATA_P4
23 SAT_DATA_P5
24 SAT_DATA_N4
25 SAT_DATA_N5
26 GND
27 SAT_DATA_P6
28 SAT_DATA_P7
29 SAT_DATA_N6
30 SAT_DATA_N7
FSD R/G PWB (PWC-4670)
POJ3 Connect to FFIB PWB
1 VCC2.5V
2 GND
3 VCC12V
4 GND
5 VCC3.3V
6 GND
7 VCC2.5V
8 GND
POJ2 Connect to FFIB PWB
1 SAT_DATA_P8
2 SAT_DATA_P9
3 SAT_DATA_N8
4 SAT_DATA_N9
5 GND
6 SAT_DATA_P10
7 SAT_DATA_P11
8 SAT_DATA_N10
9 SAT_DATA_N11
10 GND
11 SAT_RXDATA_P
12 SAT_RESETZ
13 SAT_RXDATA_N
14 SAT_PROG_B
15 SAT_RXCLK_P
16 GND
17 SAT_RXCLK_N
18 SPARE_LVTTL0
19 SAT_INIT_B
20 SPARE_LVTTL1
21 GND
22 SAT_DATA_P12
23 SAT_DATA_P13
24 SAT_DATA_N12
25 SAT_DATA_N13
26 GND
27 SAT_DATA_P14
28 SAT_DATA_P15
29 SAT_DATA_N14
30 SAT_DATA_N15
