“Confidential, Do Not Duplicate without written authorization from NEC.”
14-6
REPLACEMENT OF THE LAMP HOUSE AND BULB
7. Loosen the hexagon socket head cap screws (4mm) at the lamp bulb connecting part with the ball driver (3
mm).
8. Remove the lamp bulb from the lamp bulb connecting part with holding the both metal parts of the bulb.
Remove the bulb from the reflector.
Exercise care to avoid hitting the bulb against the reflector, lamp cover, or other hard parts.
Never touch the glass parts of the lamp bulb and the reflector mirror surface. In case of touching them, wipe
the parts as per Caution 1.
To Next Page
