53
6. Appendix
• Timing chart of GPIO control
Off at least 500 ms at least 500 ms
3-22
4-23/5-24/6-25
time
Execute
Select Macro
off
on
off
on
Example of Select Macro
approx. 200 ms
Off at least 500 ms at least 500 ms
approx. 200 ms
4-23/5-24
3-22
time
Execute
Image doused/un-doused
off
off
on
on
Example of Image doused/un-doused
Off at least 500 ms
at least 500 ms
approx. 200 ms
1-20/2-21
time
Execute
Lamp On/Off
off
on
Example of Lamp On/Off
