4
1. What’s in the Box? and the Names of the Projector Parts
1-2-3. Front Section of the Touch Panel NC-TP6401
LCD panel
A touch panel screen.
Shield button
This is not used with this controller.
1-2-4. Rear of the Touch Panel NC-TP6401 (down ward)
COM LAN RS-485
USB
POWER
OFF ON
USB port (Type A)
This is not used with this
controller.
LAN port (LAN) (RJ-45)
Use a LAN cable (Ethernet cable) to connect
the controller with the projector.
Reset button
This is not used with this controller.
External control terminal
(RS-232C)
This is not used with this
controller.
DC IN terminal (DC power
input terminal)
A power terminal. Ask the service
personnel to connect the power cable.
Holder arm mounting hole
Mount the controller to the projector
using a bracket and these holes.
Power ON/OFF switch
The main power switch of this
controller. The power of the
controller is linked with the power
for the projector (See Page 9).
External control terminal
(Bayonet-locking)
This is not used with this controller.
