NEC NEAX 2000 IPS Installation Manual

CHAPTER 2 INSTALLATION
– 138 – NWA-008841-001 Rev.5.0
90ch2001.fm
MDF Cable
To facilitate the termination of the 25 pair cables (MDF cables) from the system to the MDF shown below,
the length of each cable to be used should be predetermined according to the distance between the MDF
and the system. Each cable should be labeled at both ends using a cable number or cable designation as
shown below.
MDF Cable
TO PIM
CHAMP CONNECTOR
TWISTED 25 PAIR CABLES
TO MDF
CABLE RUNNING TO MDF
