– 558 – NWA-008841-001 Rev.5.0
90ch3004.fm
PN-8LCAK (LC)
Locations of Lamps, Switches, and Connectors
Lamp Indications
Switch Settings
This card has no switches.
LAMP
NAME
COLOR FUNCTION
BL0-7 Red • Remains lit when the corresponding circuit is in use.
• Flashes at 60 IPM when the corresponding circuit is in make-busy
state or the system data for this card is not assigned.
BL7
BL6
BL5
BL4
BL3
BL2
BL1
BL0
NOVEMBER/15/2006
PN-8LCAK (LC)
To Next Page
