– 303 – NWA-008841-001 Rev.5.0
90ch3002.fm
PN-CP15 (FP)
Locations of Lamps, Switches, and Connectors
Lamp Indications
LAMP
NAME
COLOR FUNCTION
RUN Green Flashes at 120 IPM while the circuit card is operating normally.
SENSE
RUN
MB
SW1
PN-CP15 (FP)
