16 About US110
Configuring Network
By the default setting of US110, the network is configured initially to obtain the IP address from the
DHCP server. If you want to change configuration, take the following steps.
1. On the Terminal Connection Manager, click the [Control Panel] button to open the
Control Panel window.
2. Double click [Network and Dial-up Connection].
3. Double click [NETCLIENT-NSS].
4. Select [Specify an IP address], then enter addresses for IP Address, Subnet Mask, and
Default Gateway. For settings of DNS and WINS, use the [Name Servers] tab.
NOTE: The [Control Panel] button does not appear on [Configure] tab
of Terminal Connection Manager. It appears when you select the
[Connections] tab.
