NEC US110 - Configuring ICA and RDP Connections

Using Features of US110 25
Configuring ICA and RDP Connections
To configure connections, select the desired connection entry from the [Configure] tab in Terminal
Connection Manager.
Figure 2-2 Terminal Connection Manager - Configure
The dialog box contains Connection Name, Type, and Startup option.
The Configure page has the following four command buttons.
 Add
Click [Add] to configure a new connection.
 Edit
Click [Edit] to edit or review the selected item in the connection list.
 Delete
Click [Delete] to delete the selected item in the connection list.
 Startup
Set a startup option for the selected connection entry. The selected item can be connected
automatically at startup of US110.
NOTE: Only one entry can be connected automatically at startup of
US110. If this option has already been set for any other entries, the
latest one becomes valid.
