System Map: Model B - Top View with LCD Panel Open 1 - 7
Quick Start Guide
1
System Map: Model B - Top View with LCD Panel Open
Figure 1 - 3 - Model B - Top View with LCD Panel Open
2
5
1
7
8
4
1. Optional Built-In PC Camera
2. LCD
3. Speakers
4. LED Status Indicators
5. Hot-Key Buttons
6. Power Button
7. Keyboard
8. TouchPad and Buttons
9. LED Power & Communication
Indicators
10. Built-In Microphone
6
9
3
5
6
4
10
Note: Only One Design Style is Pictured
3
Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission de-
vices aboard aircraft is usu-
ally prohibited. Make sure
the module(s) are OFF if
you are using the computer
aboard aircraft.
Use the key combinations
to toggle power to the
WLAN/Bluetooth modules,
and check the status indi-
cator icon to see if the mod-
ules are powered on or not
(see Table 1 - 3, on page 1
- 8/Table 1 - 5, on page 1 -
10).
