Features & Components
Audio Features 2 - 13
2
8 Channel Sound Support
If you wish to configure your system for 8 channel sound support, then the following
ports should be used as outputs. Double-click the appropriate icon (e.g. ) to bring
up the “Connected device:” dialog box to configure the output port.
• Side Speaker Out - Connect to S/PDIF Out
• Center/Subwoofer Speaker Out - Connect to Microphone In
• Front Speaker Out - Connect to Speaker/Headphone Out
• Rear Speaker Out - Connect to Line In
Figure 2 - 11
8 Channel Sound
Support
