Features & Components
2 - 2 Hard Disk Drive
2
Hard Disk Drive
The hard disk drive is used to store your data in the computer. The hard disk can be
taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height
of 9.5 mm.
The hard disk is accessible from the bottom of your computer as seen below. For fur-
ther details see “Upgrading the Hard Disk Drive” on page 6 - 5.
Power Safety
Before attempting to ac-
cess any of the internal
components of your
computer please ensure
that the machine is not
connected to the AC
power, and that the ma-
chine is turned off. Also
ensure that all peripher-
al cables, including
phone lines, are discon-
nected from the comput-
er.
Figure 2 - 1
Hard Disk Location
Hard Disk
Model A Model B
To Next Page
